Eicher 2050 C Chassis
The all-new 2000 series chassis is designed to deliver best in class operating economics and superior on road performance, coupled with a lower maintenance costs leading to high profitability for its owners. Powered by advanced new E366 engine, Eicher chassis is smartly designed to deliver powerful performance without compromising on fuel efficiency.
GVW5.6 t
EngineE366
Power 75 kW
Torque285 Nm
Fuel TypeDiesel
- Specification
- Technology
| SPECIFICATIONS | 2050 C |
|---|---|
| Wheelbase | 2850 mm |
| Overall Length | 5375 mm |
| Overall Width | 2043 mm |
| Overall Height | 2480 mm |
| Ground Clearance | 183 mm |
| Front Overhang | 1000 mm |
| Rear Overhang | 1525 mm |
| Turning Circle Diameter | 11.2 m |
| Engine Make | E366 |
| Displacement (cc) | 1999 |
| Power | 75 kW @ 3200 Rpm |
| Torque | 285 Nm @ 1250-2500 Rpm |
| Clutch | 280 mm |
| Transmission Make | ET30S5 |
| Transmission Type | Synchromesh ( 5 SPeed+1Rev) |
| GVW | 5.6 t |
| Chassis Type | BSK 46 |
| Chassis dimension | 180X60X5 mm |
| Fuel Tank Capacity | 60 litres |
| Brakes | Hydraulic with Disc |
| Tyres | 7.50 X 16 -16 PR |
| Suspension Front | Semi elliptic with ARB |
| Suspension Rear | Semi elliptic with ARB |
| Steering | Power steering |
| Battery | 12V, 130Ah |
| Alternator | 110A |
| DEF Tank Capacity | 19 litres |
