Eicher 2075 G AC Chassis

The all-new 2000 series chassis is designed to deliver best in class operating economics and superior on road performance, coupled with a lower maintenance costs leading to high profitability for its owners. Powered by advanced new E474 engine, Eicher chassis is smartly designed to deliver powerful performance without compromising on fuel efficiency.

GVW7.5 t
EngineE474
Power 105 kW
Torque400 Nm
Fuel TypeDiesel

Specification
Technology

SPECIFICATIONS	2075 G
Wheelbase	3870 mm
Overall Length	7089 mm
Overall Width	1990 mm
Overall Height	2480 mm
Ground Clearance	187 mm
Front Overhang	1024 mm
Rear Overhang	2195 mm
Turning Circle Diameter	14.4 m
Engine Make	E474
Displacement (cc)	2960
Power	105 kW @ 3200 Rpm
Torque	400Nm @ 1200-2500 Rpm
Clutch	310 mm
Transmission Make	ET35S5
Transmission Type	Synchromesh ( 5 SPeed+1Rev)
GVW	7.5 t
Chassis Type	Domex 650
Chassis dimension	200X75X5 mm
Fuel Tank Capacity	100 litres
Brakes	Dual Circuit 'S' Cam Full Air brakes
Tyres	7.50 X 16 -16 PR
Suspension	Semi elliptic
Steering	Power steering
Battery	12V, 130Ah
Alternator	2 x 110A
DEF Tank Capacity	19 litres

Dynamic Fuel Coaching

Fuel coaching personally guides the driver towards the right selection of gear and rpm to help achieve higher fuel economy

MBooster+

MBooster+ allows the driver to drive in different modes of load and gradient to achieve best-in-class fuel efficiency

Cruise Control

Cruise control maintains speed/rpm without pressing ABC control pedals which leads to fatigue-free driving and higher fuel economy

IDIS 2.0

Intelligent Driver Information System 2.0 keeps the driver informed of all the key parameters through an easy to read display and tell-tales.

BSVI E 474 Engine

The new E 474 BSVI engine delivers higher power and torque while remaining true to the promise of best in class fuel efficiency.
