The Domex® chassis is designed to deliver more. Light weight and reliable, it offers superior performance, APDA reduces moisture and oil from the air to increasing the life of the pneumatic system.

Assured Reliability

Best-in-class fuel efficiency delivered by Fuel coaching and Mbooster+ that enable the driver to operate in the most fuel efficient manner. Efficient engine coupled with an advance EATS ensures optimized fuel and AdBlue consumption.

Fluid Economy

New Three spoke easy to adjust steering wheel, new instrument cluster with intelligent display for better drive aids, mileage enhancing Cruise control are some of the latest feature in 2000 series.

Next Gen Features

A complete peace of mind through stronger aggregates Lubricated For Life Propeller shaft and steering, improved suspension and corrosion free HPDE adblue tank is built in the Eicher 2000 chassis series.

Long lasting Durability

Eicher offers the all new EUTECH6 Bus chassis range. The new chassis are appointed with smart & next gen features like Mbooster+, fuel coaching and new cruise control to ensure fuel efficient performance. Know about price, features, specs, etc.

Bus Chassis, Best Bus Chassis, Bus Chassis Price, Features, Specs | Eicher

<h1>Bus Chassis Buses</h1>
Eicher presents the all new EUTECH6 Bus chassis range. The new chassis are appointed with smart &amp; next gen features like Mbooster+, fuel coaching and new cruise control to ensure fuel efficient performance Equipped with powerful and fuel efficient engines, strong reliable aggregates and improved suspensions, the new Eicher bus chassis are well suited to perform in any applications.

Designed to deliver higher value, Eicher 2075 G chassis with a wheelbase  3870 mm is equipped with robust aggregates and offers best in class operating economics.

The all-new 2000 series chassis is designed to deliver best in class operating economics and superior on road performance, coupled with a lower maintenance costs leading to high profitability for its owners. Powered by advanced new E474 engine, Eicher chassis is smartly designed to deliver powerful performance without compromising on fuel efficiency.

The all-new 2000 series chassis is designed to deliver best in class operating economics and superior on road performance, coupled with a lower maintenance cost

2075 G Chassis : Eicher 2075 G Chassis  Price, Specifications, Features & Gallery | Eicher Trucks and Buses

Introducing the all-new 2000 series high performance Eicher bus chassis. The new chassis offers best-in-class mileage & power from the advanced and reliable next generation of EUTECH6 drivelines.

2000 Series Bus Chassis | Bus Chassis Price in India | Eicher

<h1>2000 Series Bus Chassis</h1>
Introducing the all-new 2000 series high performance Eicher bus chassis. The new chassis offers best-in-class mileage & power from the advanced and reliable next generation of EUTECH6 drivelines. The new 2000 series chassis is suited for varied applications to ensure lifelong profitability.

Fuel coaching personally guides the driver towards the right selection of gear and rpm to help achieve higher fuel economy

Dynamic Fuel Coaching

MBooster+ allows the driver to drive in different modes of load and gradient to achieve best-in-class fuel efficiency

MBooster+

&nbsp;Cruise control maintains speed/rpm without pressing ABC control pedals which leads to&nbsp;fatigue-free driving and higher fuel economy

Cruise Control

Intelligent Driver Information System 2.0 keeps the driver informed of all the key parameters through an easy to read display and tell-tales.

IDIS 2.0

The new E 474 BSVI engine delivers higher power and torque while remaining true to the promise of best in class fuel efficiency.

SPECIFICATIONS	2075 G
Wheelbase	3870 mm
Overall Length	7089 mm
Overall Width	1990 mm
Overall Height	2480 mm
Ground Clearance	187 mm
Front Overhang	1024 mm
Rear Overhang	2195 mm
Turning Circle Diameter	14.4 m
Engine Make	E474
Displacement (cc)	2960
Power	90 kW @ 3200 Rpm
Torque	350Nm @ 1200-2500 Rpm
Clutch	310 mm
Transmission Make	ET35S5
Transmission Type	Synchromesh ( 5 SPeed+1Rev)
GVW	7.5 t
Chassis Type	Domex 650
Chassis dimension	200X75X5 mm
Fuel Tank Capacity	100 litres
Brakes	Dual Circuit 'S' Cam Full Air brakes
Tyres	7.50 X 16 -16 PR
Suspension	Semi elliptic
Steering	Power steering
Battery	12V, 130Ah
Alternator	110A
DEF Tank Capacity	19 litres

Eicher 2075 G Chassis

Dynamic Fuel Coaching

MBooster+

Cruise Control

IDIS 2.0

BSVI E 474 Engine
