Eicher 2112 M Chassis
The all-new 2112 M AC chassis is built strong with domex® material, silent and low maintenance suspension, radial tyres and many other advance features making it an ideal options for any application. BSVI chassis is driven by state-of-the-art E494 engine which provides powerful performance. Its superior fuel efficiency coupled with lower maintenance cost leads to high profitability for its stakeholders.
GVW13.1 t
EngineE494
Power 120 kW
Torque500 Nm
Fuel TypeDiesel
- Specification
- Technology
| SPECIFICATIONS | 2112 M |
|---|---|
| Wheelbase | 5330 mm |
| Overall Length | 9856 mm |
| Overall Width | 2413 mm |
| Overall Height | 2785 mm |
| Ground Clearance | 232 mm |
| Front Overhang | 1370 mm |
| Rear Overhang | 3156 mm |
| Turning Circle Diameter | 19.4 m |
| Engine Make | E494 |
| Displacement (cc) | 3770 |
| Power | 120 kW @ 2600 Rpm |
| Torque | 500 Nm @ 1200-1800 Rpm |
| Clutch | 330 mm |
| Transmission Make | ET40S6 |
| Transmission Type | Synchromesh (6SPeed+1Rev) |
| GVW | 13.1 t |
| Chassis Type | Domex 650 |
| Chassis dimension | 210 X 76 X 6 mm |
| Fuel Tank Capacity | 190 litres |
| Brakes | Dual Circuit 'S' Cam Full Air brakes |
| Tyres | 9R20-16PR |
| Suspension | Wevellar Suspension |
| Steering | Power steering |
| Battery | 12V 130AH |
| Alternator | 110A |
| DEF Tank Capacity | 27 litres |
