GVW(Kg) |
16000 |
Wheelbase(mm) |
4300 |
4800 |
5340 |
Cargo Body Length (ft) |
18 |
20 |
24 |
Engine Type |
E683 6 Cylinder, Water Cooled BS III |
Max Power |
154 HP @ 2400 RPM |
Max Torque |
600 Nm @ 1400-1600 RPM |
Clutch Dimension and Type |
352mm with Booster, Push Type |
Gearbox |
ET90 |
Rear Axle |
Fully Floating Banjo Type |
Chassis Type |
Ladder Frame |
Suspension |
Front: Semi-elloptic leaf spring with hyd. Type double acting telescopic FR shock absorber
Rear: Semi-elliptic leaf spring with helper suspension |
Steering |
Power Steering, 480 mm |
TCD (m) |
16.9 |
18.8 |
20.8 |
Gradiability(%) |
38 |
38 |
38 |
Max Speed (kmph) |
87 kmph |
87 kmph |
87 kmph |
Fuel Tank (L) |
220L Metallic Tank |
Battery |
2x12V - 120 Ah |
Tyre |
Front: 10x20-16PR (Rib) Rear and Spare: 10x20-16PR (Lug) |
Front: 10R20 (Rib) Rear and Spare: 10R20 (Lug) |
Front: 10R20 (Rib) Rear and Spare: 10R20 (Lug) |
