EicherPro 6025T

Eicher Pro 6025T is the new generation 25 ton GVW tipper equipped with highly fuel efficient VEDX8, 6 cylinder,7.7 litre CRS engine designed in association with Volvo Group and a Next Gen cabin with state of art features.

GVW25000 kg
EngineVEDX8
Power220 hp
Torque850 Nm
Transmission 9 Speed
Tipper Body Size14/16 cum

Specification
Applications
Benefits

Locate A Dealer
Service Van

SPECIFICATIONS	Eicher Pro 6025T
GVW	25000 kg
Wheelbase	4000 mm
Front overhang	2085 mm
Rear Overhang	1926 mm
TCD	14.5 m
Engine Type	VEDX8 BSIII 7.7 liters
Max Power	220 hp @ 2200 rpm
Max Torque	850 Nm @1100-1700 rpm
Clutch Type	Booster assisted pull type
Clutch Diameter	430 mm
Gearbox	ZF make, 9 Forward 1 Reverse
Rear Axle	Meritor Tandem-Fully floating Banjo
Final Drive Ratio	5.29
Chassis Type	Domex650 ladder type joggle frame, 285 x 76 x 7 mm
Suspension	Front: Semi-Elliptical with anti roll bar Rear: Bogie suspension Hydraulic double acting telescopic type at front only
Shock Absorbers	Hydraulic Double Acting Telescopic type at front only
Steering	Tilt and Telescopic hyadraulic power steering
Body Size	16 Cum Box & 14 Cum Rock
Gradiability(%)	42.50%
Max Speed	79.6 kmph
Fuel Tank	220 litres
Electrical	2 x24 V, 150 Ah
Tyre	11R-22.5 (Tubeless)- 16PR

EicherPro 6025T

Road Construction

Blue Metal

Stone

Sand

Best in class torque at wheel

high reliablity and durablity

optimized maintenance cost

Superior uptime

Faster turn around time

High fuel efficiency

unmatch cabin comfort
