EicherTerra 16XP

Eicher Terra 16XP is new range of value enhanced heavy duty 16 ton GVW tipper equipped with highly fuel efficient E683, 6 cylinder, BSIII engine designed in association with Volvo Group.

GVW16200 kg
EngineE683 TCI
Power154 hp
Torque570 Nm
Transmission ET 80 S6
Tipper Body Size8.5/10

Specification
Applications
Benefits

Locate A Dealer
Service Van

SPECIFICATIONS	Eicher Terra 16XP
GVW	16200 kg
Wheelbase	3485 mm
Overall Length	6225 mm
Overall width	2460 mm
Overall Height	3180 mm
Turning Circle Diameter	14.03 m
Engine Type	E683 6 cylinder TCI
Max Power	154 hp @ 2600 rpm
Max Torque	570 Nm @ 1440 rpm
Transmission	ET 80-6S (6 forward, 1 reverse)
Clutch Diameter	352 mm
Front Axle	Heavy duty forged 'I' beam Reverse Elliot type
Rear Axle	Heavy duty fully floating banjo type
Final Drive Ratio	6.428
Suspension	Semi elliptical laminated leaf springs, variable rate in front & rear. Hyd. Type double acting shock absorbers at front only
Steering	Hydraulic Power Assisted
Gradiability(%)	31.00%
Fuel Tank	220 litres
Electrical	12 V
Tyre	10x20-16PR (Radial opt.)
Body Size & Type	8.5 & 10 Cum Box Type

EicherTerra 16XP

Road Construction

Blue Metal

Sand

Stone

Superior uptime

Better load carrying capacity

Faster turn around time

High fuel efficiency

Low maintenance cost
