Parameters |
Value |
ENGINE |
Type |
E494 Euro-III |
Max. Power |
147 HP @ 2600 rpm |
Max. Torque |
490 Nm @1400-1600 rpm |
Displacement |
3770 cc |
Performance |
Gradebility |
40% |
TCD |
14 m |
Clutch |
Type |
330 mm dia Clutch with clutch booster |
Gearbox |
Model |
ET40S6 |
Type |
6 forward +1 reverse with OD, Cable type GSL |
AXLE |
Front |
I - Beam Reverse Elliot type |
Rear (FDR) |
4.33 FDR |
Wheel Rim & Tyre |
Tyre Size |
11R22.5 - 16 PR Tubeless Radial |
Front, Spare and Rear Tyres |
235 / 75 R 17.5 14 PR |
Suspension |
Front & Rear |
Parabolic Spring |
Shock Absorber |
2 nos of Hydraulic shock absorber |
Steering |
Type |
Power Steering, Column tilt and Telescopic with column cover |
Electrical |
Battery |
2 X 12 Volt, 130 AH |
Alternator |
24V with 75 amp & 24V with 120 amp |
System Voltage |
24Volt |
Battery Cut off |
Electric 24 V, 250 Amps |
Fuel Tank |
Fuel tank Capacity |
100 litres |
Ad-Blue Tank |
- |
Brakes |
Service Brake |
Air operated Dual circuit, Front -Disc brake & Rear - Drum Brake/ S-cam |
Brake Features |
ABS with APDA |
Brake Features |
3x2 configuration |
Seats |
Seating Capacity |
35+D (2x2) |
Type |
HHR |
Dimensions |
Wheel Base |
4320 mm |
Front Overhang |
2000 mm |
Rear Overhang |
2601 mm |
Length |
8921 mm |
Width |
2395 mm |
Height |
1950 mm |
GVW (with (90% fuel) |
8850 kg |
AC |
AC Make |
Eberspecker/spheros 31 kw |
Max cooling capacity (kW) |
31KW |
