The Eicher Skyline Pro 3009 bus is designed with breakthrough technology to redefine the passengers’ daily travel experience. This bus guarantees a journey which is safe, pleasant and comfortable. Built and assembled at Eicher’s state-of-the-art bus manufacturing plant, the new-generation Skyline Pro 3009 promises to deliver a relaxed and luxurious experience to travellers with its spacious interiors and aesthetic looks. Opt for Eicher Skyline Pro 3009 opt for guaranteed reliability and efficiency!
SPECIFICATIONS | Skyline Pro 3009 | |
---|---|---|
Dimension | GVW(Kg) | 10500 |
Overall Length (mm) | 10439 | |
Wheelbase(mm) | 5260 | |
Front overhang (mm) | 2045 | |
Rear overhang (mm) | 3134 | |
Engine | Type | E483 |
Max Power | 114hp @3200 rpm | |
Max Torque | 400Nm @1400- 1600 rpm | |
Gear Box | Model | ET35S6 (6 Forward + 1 reverse with OD) |
Clutch | Size and Type | 310 mm with booster |
Electrical | Battery | 12V- 150 Ah |
Braking System | Parking Brakes | Part of service brake Acting at RearWheels |
Service Brakes | Dual Circuit S- cam full airbrake | |
Tires and Wheels | Front & Spare and Rear | 235/75 R17.5, 14PR Tubeless radial |
Others | Steering Type | Power Steering |
Fuel Tank Capacity (L) | 160 | |
Suspension System | Front and Rear | Parabolic Suspension with Antirollbarmechanism |
Performance | Gradeability | 26% |
TCD (m) | 19 |
