| Vehicle Name |
Pro 6025RMC |
| Drive |
6X4T RHD |
| GVW |
25500 |
| FAW |
7500 |
| RAW |
18000 |
| Kerb Weight |
12639 |
| Vehicle Outline |
| Wheel Base (mm) |
4000 |
| Vehicle FOH (mm) |
1430 |
| Chassis ROH (mm) |
1368 |
| Vehicle ROH (mm) |
2390 |
| Vehicle Over All Length (FBT) mm |
8495 |
| Max Width (mm) |
2600 |
| Frame |
| Type |
Rolled C-Channel Ladder Type joggle, |
| Section |
285x76x7 THK |
| Engine |
| Model |
VDEX8 - EURO 3 |
| Description |
Turbo Charged , DI Diesel Engine |
| Max Power |
280HP @ 2200 rpm (209Kw) |
| Max Torque |
1050 Nm @ 1100 - 1700 rpm |
| Transmission |
| Gear Box |
ET140S9 |
| Clutch |
| Clutch |
430Dia. Booster Assisted, Pull Type |
| Rear Axle |
| Type |
Fully floating banjo type |
| Make |
VECV |
| Ratio (FDR) |
5.286 |
| Front Axle |
| Type |
ETB Forged I Beam |
| Steering System |
| Type |
Power steering |
| Steering Wheel Dia |
460mm |
| Suspension |
| Front Suspension |
Parabolic Spring with Hyd. typ.
Double acting Telescopic FR Shock Absorber |
| Rear Suspension |
Bogie Suspension |
| Wheels & Tires |
| Type |
Radial Tyre |
| Tire Size - front |
315/80R22.5 RIB TYRE |
| Tire Size - Rear & Spare |
315/80R22.5 LUG TYRE |
| SWC |
Side Mounted STC |
| Cabin / Cowl |
| Type |
Day cabin with integrated foot step |
| Suspension Type |
Fully Suspended Cabin |
| HVAC / Blower |
HVAC |
| Body |
| Body Type |
RMC with 8CuM |
| Brakes |
| Type |
Drum Brake at front & Rear |
| Size(Fr/Rr) |
410x200-FRNT & 410x220-RR |
| Service |
S-Cam fully Air Brakes |
| ABS |
Yes |
| Electrical |
| System |
24V |
| Battery |
2x12V - 120 Ah |
| Fuel Tank |
| Type |
Plastic |
| Size |
220L |
| Performance |
| Gradeability |
38% |
| Max Speed |
88 |
GVW25500 kg
EngineVDEX8
Power280HP
Torque1050 Nm
