| Parameters |
Value |
| ENGINE |
Type |
E494 Euro-III |
| Max. Power |
147 HP @ 2600 rpm |
| Max. Torque |
490 Nm @1400-1600 rpm |
| Displacement |
3770 cc |
| Performance |
Gradebility |
40% |
| TCD |
14 m |
| Clutch |
Type |
330 mm dia Clutch with clutch booster |
| Gearbox |
Model |
ET40S6 |
| Type |
6 forward +1 reverse with OD, Cable type GSL |
| AXLE |
Front |
I - Beam Reverse Elliot type |
| Rear (FDR) |
4.33 FDR |
| Wheel Rim & Tyre |
Tyre Size |
11R22.5 - 16 PR Tubeless Radial |
| Front, Spare and Rear Tyres |
235 / 75 R 17.5 14 PR |
| Suspension |
Front & Rear |
Parabolic Spring |
| Shock Absorber |
2 nos of Hydraulic shock absorber |
| Steering |
Type |
Power Steering, Column tilt and Telescopic with column cover |
| Electrical |
Battery |
2 X 12 Volt, 130 AH |
| Alternator |
24V with 75 amp & 24V with 120 amp |
| System Voltage |
24Volt |
| Battery Cut off |
Electric 24 V, 250 Amps |
| Fuel Tank |
Fuel tank Capacity |
100 litres |
| Ad-Blue Tank |
- |
| Brakes |
Service Brake |
Air operated Dual circuit, Front -Disc brake & Rear - Drum Brake/ S-cam |
| Brake Features |
ABS with APDA |
| Brake Features |
3x2 configuration |
| Seats |
Seating Capacity |
35+D (2x2) |
| Type |
HHR |
| Dimensions |
Wheel Base |
4320 mm |
| Front Overhang |
2000 mm |
| Rear Overhang |
2601 mm |
| Length |
8921 mm |
| Width |
2395 mm |
| Height |
1950 mm |
| GVW (with (90% fuel) |
8850 kg |
| AC |
AC Make |
Eberspecker/spheros 31 kw |
| Max cooling capacity (kW) |
31 KW |
