Eicher Pro 2055XP is here to address the transportation needs in the Middle East. Its comfort & safety along with next gen features puts it miles ahead of its competition. It is the Smart choice for the last mile delivery of goods.
SPECIFICATIONS | Pro 2055XP |
---|---|
Drive | LHD |
Body Size | 10, 12ft |
Body Type | CBC/DSD |
Vehicle Weight (in Kg) | |
GVW (laden) (Kg) | 6250 |
FAW (laden) (Kg) | 2465 |
RAW (laden) (Kg) | 3785 |
Kerb Weight (kg) | 2624/3059/2634/3134 |
FAW (Unladen) Kg | 1679/1682/1685/1724 |
RAW (Unladen) Kg | 944/1376/948/1409 |
Vehicle Dimensional Parameters | |
Front Track (mm) | 1525 |
Rear Track (mm) | 1455 |
Wheel Base (mm) | 2670/ 2935 |
Overall Length (mm) | 5250/5350/5575/5780 |
Overall Height (mm) | 2355 |
Overall Width (mm) | 2270 |
FOH (mm) | 1200 |
ROH (mm) | 1380/1480/1440/1645 |
Ground Clearance (mm) | 175 |
Frame | |
Type | Joggle Frame |
Section (H x W x Thk) (mm) | 172x60x5 |
Frame Width (Front & Rear) | F-750 & R-680 |
No. of X-MBRS
|
5 |
(except Engine mount C/M & Rear shock abs C/M) | |
Fuel Tank Type & Size | Polymer with ROV, 60L |
Engine | |
Model Name | E474 |
Type of Fuel | Diesel |
Emission | Euro 5 |
Displacement (Ltrs) | 2.96 |
Max Power (HP) | 150HP @3200 |
Max Torque (Nm) | 400 |
Provision of pully for additional Compressor | Yes |
Cold Start | |
Transmission | |
Gear Box | ET35S6 |
Gear Ratio forward | 6.667~0.83 |
Gear Ration Reverse | 5.94 |
PTO | No |
Gear Shift | |
Type | Hybrid cable type |
No. of Gears | 6 + 1 |
Clutch | Single dry plate |
Clutch (Type\Size) | Dia 310 |
Booster | NA |
Prop Shaft | |
Series | SPL55 |
Diameter | 88.9 |
Performance | |
Max Speed (kmph) | 106 |
Grade ability (%) | 40 |
Front Axle | |
Type | Reverse Elliot “I” Beam |
Rear Axle | |
Drive Head Size (mm) | 305 |
Rear Axle Ratio | 4.3 |
Diff Lock | No |
Steering System | |
Type | Power Steering |
Tilt able (Y\N) | Yes |
Steering Wheel Dia (mm) | 410 |
Stg Gear Box Ratio | 19.8 |
TCD –calculated (m) | 10.5/11.5 |
Suspension | |
Front Suspension Type | Semi Elliptical with Anti roll bar & Shock Abs |
No of leaves (nos) | 8 |
Width X Thickness (mm) | 70 x 9-4, 70x8-4 |
ARB | |
Rear Suspension Type | Semi Elliptical with rear shock Absorber |
No of leaves | M-9, H-7 |
Width X Thickness (mm)
|
M-70x10-1nos, |
M-70x9-8nos, | |
H- 70x8- 7nos | |
ARB | |
Wheels & Tyres | |
No. of Tyres (Excluding STC) | 6 |
Tyre Type | Tubeless |
Tyre Size (Front & Spare) | 215/75R17.5 |
Tyre Size (Rear) | 215/75R17.5 |
Wheel Rim size | 6X17.5 |
No. of Bolts \ Rim | 5 |
Cabin | |
Width | 1.8m |
Day \ Sleeper | Day |
Drive | LHD |
Seating Capacity | 3 |
Tilt Mechanism | Manual |
Seat Belt (Driver) | 3 point ELR with SBR |
Seat Belt (Co-driver) | 3 point ELR |
Co-driver Lap Belt | Yes |
HVAC \ Blower | HVAC |
Power Window | Yes |
Central Locking | Yes |
Rear Window | Fixed |
Overhead Storage Box | Yes |
Carpet | Moulded type |
Brakes | |
Type ( Air \Hyd) | Dual Circuit Hydraulic |
Brake type | Drum Brake |
Front disc piston dia. | NA |
Rear disc piston dia. | NA |
Brake Assy dia. | NA |
Drum Size | 320 x 110 |
Parking Brakes type | Internal Expanding Type at rear of transmission. |
Brake Booster Size (Hyd) | 8+9" |
Parking brake dia. | 220 |
No of Vacuum / Air Tanks | 1 |
Tank Capacity | 3.5L |
ABS (Yes\No) | YES |
Exhaust brake | Yes |
Exhaust brake dia. | 79 mm |
Electrical | |
Voltage System | 24V |
No. of batteries | 2 |
Battery Rating | 100Ah |
Battery Cut off | Yes |
Fog lamp | Yes |
Tail Lamp | LED type |
Wiping System | 2 blade with arms, operated by electric motor |
Alternator | 75A |
Music System (Radio) | No |
Infotainment System | Yes |
M Booster / M Booster + | M Booster + |
Hydraulic Jack | Yes |
Fire Extingusher | Yes |
