GVW(Kg) |
25000 |
Body Options |
16 Cum, Box Type |
14 Cum, Box Type (Optional) |
Wheelbase(mm) |
4000 |
Max Power |
180 hp @ 2500 rpm |
Max Torque |
685 Nm @ 1500 rpm |
Clutch Type |
Coil spring push type |
Clutch Dia. |
380 mm |
Gearbox |
ZF 1110TD (8 Forward, 1 Crawler & 1 Reverse) |
ET 80 (6 Forward & 1 Reverse) (Optional) |
Front Axle |
Reverse Elliot type I Beam |
Rear Axle |
Meritor Axle |
Chassis Type |
Rolled C-Channel Straight Frame, 285x76x7 mm |
Front Suspension |
Semi-elliptical leaf spring w/o Anti-roll Bar |
Rear Suspension |
Bogie Suspension |
Bell Crank Suspension (Optional) |
Steering |
Hydraulic Power Steering |
TCD (m) |
15.8 |
Gradeability(%) |
43 |
Max Speed (kmph) |
70 |
Fuel Tank (L) |
220 |
Battery |
24V |
Tyre |
Front - Std. 10x20-16PR (Rib Pattern)
Rear & Spare - Std. 10x20-16PR (Lug Pattern) |
