EicherPro 6016
The design and development of Eicher Pro 6016 provides unparalleled business advantage by maximizing efficiency right through the life-cycle of the vehicle and minimizing the cost of operations. Eicher Pro 6016 is a highly-reliable 16 ton GVW truck powered with the next generation 5.1 litre VEDX5 CRS technology engine designed in collaboration with Volvo group. The 4 cylinder, 4 valve engine has high combustion efficiency and low parasitic losses and delivers 210 HP and 825 NM torque, resulting in class-leading fuel efficiency.
GVW16000 kg
EngineVEDX5
Power210 Hp
Torque825 Nm
Transmission ET70S6
| SPECIFICATIONS | Pro 6016 |
|---|---|
| GVW(Kg) | 16000 |
| Wheelbase(mm) | 5340 |
| Front Overhang (mm) | 1423 |
| Rear Overhang (mm) | 2824 |
| Engine Type | VEDX5, 4 cylinder, 4 valve per cylinder, turbo charged, intercooled diesel, commom rail |
| Max Power | 210 @ 2200 rpm |
| Max Torque | 825 @ 1200-1600 rpm |
| Clutch Type | Spring loaded push type |
| Clutch Diameter (mm) | 395 |
| Gearbox | ET70S6 (6 forward, 1 reverse) |
| Emission | Euro III |
| TCD (m) | 18 |
| Max Speed (km/hr) | 110 |
| Chassis Type | Ladder type joggle frame (285x76x7) |
| Suspension | Front: Semi elliptical leaf springs with double acting telescopic shock absarber & Anti-roll bar Rear: Semi elliptical laminated leaf springs |
| Steering | Power steering |
| Gradeability(%) | 34.5 |
| Fuel Tank (L) | 220 |
| Electrical | 24.V.150AH |
| Tyre | Tubeless Radial 295/80R22.5-16PR |
Water Tanker/Fuel Tanker/Chemicals
Voluminous Goods
Refrigerated Van
Parcel & Courier & FMCG
Municipal Application
Market Loads
Electrical Appliances (White Goods)
Dsd With Crane
Beverages (Bottles & Cans)
FMCG
Superior Uptime
Intelligent Driver Information System
Class leading fuel efficiency
Cabin Adapted from Japanese design for Comfort, Safety & Efficiency
