EicherPro 6016T
The new Eicher 6016T is a 16 tonne GVM Tipper. With power of 210 HP and torque output of 825 Nm, the Eicher Pro 6016T is built on the philosophy of BORN EFFICIENT
GVW16000 kg
EngineVEDX5
Power210 Hp
Torque825 Nm
Transmission ET70S6
Body Size/Type6 CuM
| SPECIFICATIONS | Pro 6016T |
|---|---|
| GVM(Kg) | 16000 |
| Wheelbase(mm) | 3900 |
| Front Overhang (mm) | 1423 |
| Rear Overhang (mm) | 1060 |
| Engine Type | VEDX5, 4 cylinder, 4 valve per cylinder, turbo charged, intercooled diesel, commom rail |
| Max Power | 210 @ 2200 rpm |
| Max Torque | 825 @ 1200-1600 rpm |
| Clutch Type | Spring loaded push type |
| Clutch Diameter | 395 |
| Gearbox | ET70S6 (6 forward, 1 reverse) |
| Final Driver Ratio | 5.286 |
| Shock Absorbers | Double acting telescopic shock absorbers |
| Body Size/ Type (cum) | 6 |
| Max Speed (km/hr) | 110 |
| Chassis Type | Ladder type joggle frame (285x76x7) |
| Suspension | Semi elliptical leaf spring |
| Steering | Power steering |
| Gradeability(%) | 37 |
| Fuel Tank (L) | 220 |
| Electrical | 2 x 12V - 120 Ah |
| Tyre | Tubeless Radial 295/80R22.5-16PR |
Sand
Stone
Blue Metal
Road Construction
